1. Testing items: area, location, foreign objects, presence of holes, tension level;

2. The measurement accuracy of the opening position is 5 μ m;

3. Detection speed of 6 minutes (300 * 250mm);

4. Repeatability and reproducibility optimization GAGE R&R<5%;

5. High precision servo motor, grating ruler (X. Y-axis servo motor grating ruler/repeatability ± 5 μ m resolution 1 μ m/Pulse)

6. GERBER and steel mesh automatic alignment, no need for multiple teaching sessions; The GERBER file (RS-274X) is automatically detected using the GERBER file and has the function of comparing new and old steel mesh data;

7. Automatically generate detection reports based on inspection results, ensure data traceability, and automatically save detection data;

8. Poor image FOV 10 * 10; Minimum detection element 01005 (inch).
